Overview

Provisur’s powerful, compact Formax SX330 slicer takes on your short runs and rapid changeovers of meats and cheese with ease and efficiency. It can also be configured to meet your application requirements, including manual or automatic loading and a simple bulk conveyor or scales. And it has the blade speeds and larger throat to deliver even higher productivity as your business grows.

Benefits

  • Versatile slicer capable of slicing a wide range of products with minimal change over time
  • High performance and throughput in a compact footprint to enhance short-run slicing processes
  • Flexible configuration to meet your production needs
  • Manual and Automatic loading models to increase efficiency and lower your total cost of ownership
  • Hygienic design with tool-free disassembly

Applications

  • Lunchmeat – calibrated or irregularly shaped
  • Cheese
  • Natural shaped, whole muscle products (examples: streaky bacon, back bacon, chicken, roast beef bombs)

Presentation Options

  • Stacked
  • Shingled
  • Shaved/bunched
  • Geometric patterns
  • Overlapped pattern
  • Side shingle

Specifications


SX330 – Manual
SX330 – Automatic
Throat Area 160 mm x 330 mm /
6.3″ x 13″		 160 mm x 330 mm /
6.3″ x 13″
Number of Product Drives 1 1
Product Length 1000 mm / 39.4″ 1000 mm / 39.4″
Blade Speed (RPM) 1000 involute  1500 involute
Blade Retract None Standard
Product Loading Manual side Automatic rear center
Lower Infeed Slide plate Driven conveyor
Upper Infeed Non-driven upper paddles Non-driven upper paddles
Bulk Conveyor Standard 1220 mm / 48″
Optional 1830 mm / 72″
2440 mm / 96″		 Standard 1220 mm / 48″
Optional 1830 mm / 72″
2440 mm / 96″
Stacking Conveyor Optional Optional
Scales and Classifiers Optional 1 or 2 lanes Optional 1 or 2 lanes
3-D Product Scanner Not compatible Optional
 Interleaver Optional, up to 2 lanes* Optional, up to 2 lanes*
Options and Peripherals Infeed staging conveyor
3D product scanner
Slice folding
XY conveyor for geometric patterns
Blade honer
Simple transfer conveyor
Automated portion handling systems – autoloaders, overlappers, buffering stations, inliners and twinliners

*The multiple lane Interleaver option for SX series of slicers is not available for sale in the UK and Germany.
